HONDA GAS POWERED COMPRESSORS
COMPRESSOR + GENERATOR + WELDER
GENERATOR – 5500 Watts
(surge 5000 Watts)
- 2 X 115 Volt / 17 Amp Outlets
- 1 X 230 Volt / 23 Amp Outlet
WELDER – 240 Amp DC Arc
- Universal 55mm quick connects
- Duty Cycle: 130A = 100%, 180A = 60%, 240A = 35%
GAS HONDA – 2 STAGE – W/THROTTLE CONTROL, FUEL TANK, & 12V ALTERNATOR
| Honda Model | Starter Type | Tank Gal./Type | Pump R.P.M | CFM @ 0-PSI | [email protected] 175 PSI | LxWxH | Wt. (lbs) | Unit Model |
| GX270 | Rope | 30 Horiz. | 808 | 24.7 | 19.7 | 43x22x42 | 500 | I 9GH3HC1 |
| GX390 | Rope/elec. | 30 Horiz. | 995 | 35.0 | 28.1 | 43x22x42 | 550 | I 13GH3HC1 |
| GX390 | Rope/elec. | 30 Horiz. | 635 | 37.0 | 30.3 | 48x22x40 | 700 | I 13GH3HC2 |
| GX630 | Elec. | 30 Horiz. | 885 | 55 | 43.6 | 50x34x43 | 750 | I 20GH3HC2 |
| GX390 | Rope/elec. | 30 Horiz. | 808 | 24.7 | 19.7 | 48x23x42 | 650 | I 13GH3HC1GW |
Honda Oil Drain Kits: Mounted
| Part # | Description |
| HON1010 | GX100 – GX200 |
| HON1012 | GX240 – GX390 |
| HON1420 | GX630 – GX660 |
