RIGHT FROM THE START KITS
- For piston compressors only.
- Saves 10% – vs. – buying separately.
INDUSTRIAL & COMMERCIAL
| RFS001 | RFS002 | |
| Kit | A8, C1, C2 | C3 |
| Includes | Qty | Qty |
| GA30W | 1 | 2 |
| VP100 | 4 | 4 |
| BV75 | 1 | |
| BV100 | 1 | |
| BV114 | ||
| VA075 | 1 | |
| VA100 | 1 | |
| VA125 | ||
| 16D | 2 | 2 |
DUPLEX & TANDEM
| RFS001D | RFS002D | RFS003D | |
| Kit | 10HP | 15 & 20HP | 25 & 30HP |
| Includes | QTY | Qty | Qty |
| GA30W | 2 | 2 | 4 |
| VP100 | 4 | 4 | 4 |
| BV75 | 1 | ||
| BV100 | 1 | ||
| BV114 | 1 | ||
| VA075 | 1 | ||
| VA100 | 1 | ||
| VA125 | 1 | ||
| 16D | 4 | 4 | 4 |
CAST-LUBE Oil: GA30W (gallon 30 wt.) Your new compressor needs to have the break-in oil changed within the first eight hours of operation. Air compressors have different needs than engines and failure to use a premium quality air compressor oil such as CAST-LUBE could lead to carbon build up or damage to internal working Parts and could void your warranty.
Rubber Vib., Pads: VP100 (4”x4”x1”) To ensure quiet trouble free operation for years to come, your new “Castair” compressor needs to be mounted on quality vibration pads.
Ball Valve Full Flow: BV75 (¾”), BV100 (1”), BV114 (1 ¼”), Brass/stainless steel ball valve to provide reliable tank shut- off.
Flex Hose: VA075 (¾”), VA100 (1”), VA125 (1 ¼”), Vibration absorbing stainless steel flex hose, a must to prevent vibration and pipe breakage between your compressor and shop piping.
Air Filter Elements: 16D or 20DP It is vital to performance and long pump life to keep your air filters clean.
ADJUSTABLE BELT TENSIONING MOTOR BASES
- Quickly adjust belt tension without removing your beltguards.
- Double bolt design to insure proper alignment.
| HP | Part # | Part # |
| Loose | Mounted | |
| 5 | 184D | 184DM |
| 7.5 & 10 | 213D | 213DM |
| 7.5 & 10 | 215D | 215DM |
| 15 | 254D | 254DM |
| 20 | 256D | N/A |
| 25 & 30 | 284D | N/A |
